HAND TOOLS - VICESIn Stock
PRECISION GRINDING VICES
Product Overview
High precision grinding vices for accurate machining operations with superior stability and durability.
Key Features
Manufactured from tool steel hardened 55-60 HRC
High precision ground surfaces
Rapid positioning notches allow locking in any position with provided hex key
V Grooves in sliding jaw (horizontal and vertical) for holding round jobs
Jaw pressure is forward and downward for repeatable positioning
Maximum holding power with secure clamping
Technical Specifications
Detailed technical data and measurements
Article No. | Length(mm) | Width(mm) | Height(mm) | Jaw Width(mm) | Jaw Opening(mm) | Jaw Depth(mm) | Net Weight(Kg) |
|---|---|---|---|---|---|---|---|
| TNXV-32 | 90 | 51 | 26 | 50.8 | 47 | 19 | 0.6 |
| TNXV-33 | 113 | 60 | 45 | 59.8 | 58 | 26 | 1.5 |
| TNXV-34 | 113 | 88 | 45 | 87.8 | 52 | 25 | 2.5 |
| TNXV-35 | 197 | 70 | 68 | 69.8 | 100 | 40 | 4.3 |
| TNXV-36 | 240 | 93 | 90 | 92.8 | 105 | 44 | 10 |
| TNXV-37 | 255 | 93 | 90 | 92.8 | 128 | 44 | 10.5 |
