PRECISION MODULAR MACHINE VICES
Product Overview
Heavy-duty modular machine vices suitable for 3-axis machining operations with precision ground surfaces.
Key Features
Manufactured from heavy duty close grained high tensile seasoned cast iron
Precision ground bearing surface flatness within 0.0007″ (20 microns)
Suitable for 3-axis jobs: milling, surface grinding, drilling, jig boring, shaping
Can be used as low profile machine vice or with universal tilting table
Tilting movement: 0° to 45° each side
Horizontal movement: 0° to 90° each side
Fixed rotary base adjustable 0° to 90° (360°)
Vice jaws fully hardened and ground with parallelism within 0.0012″ (30 microns)
Jaw hardness: 55±5 HRC
Accurately machined table T-slots
Technical Specifications
Detailed technical data and measurements
Article No. | L(mm) | L1(mm) | H(mm) | L1(mm) | W1(mm) | H1(mm) | W(mm) | E(mm) | F(mm) | Net Weight(Kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| TNXMMV-71 | 200 | 95 | 133 | 125 | 100 | 22 | 50 | 50 | 25 | 7 |
| TNXMMV-72 | 267 | 134 | 178 | 200 | 150 | 28 | 75 | 75 | 33 | 20 |
| TNXMMV-73 | 342 | 172 | 228 | 250 | 200 | 40 | 100 | 100 | 38 | 41 |
